1/2″ Combination Boiler Feed Valve & Backflow (NPT x Sweat)

Description

The integral design of the Taco 3450 Combi Valve combines a cartridge style backflow
preventer with a pressure regulating cartridge style boiler feed valve into a unique
one piece body configuration. Taco’s 3450 combination dual check backflow with
atmospheric vent and boiler feed valve with purge auto-reset, dial in pressure setting
and adjustable indicator sets a new standard for performance and serviceability.

Designed for use in hydronic heating systems the duel
check backflow prevents heating system water from flowing back into the
supply water piping if the supply pressure falls below the heating system
pressure. The boiler feed valve automatically fills or refills (make-up water)
the closed heating system to the desired cold fill pressure. Both the backflow
and the feed valve contain cartridges that can be serviced or replaced
without draining the entire heating system.

Features
Auto Reset from Fast Fill
ASSE 1081-2014
Simple Pressure Adjustment
Servicable Cartridge for both the Backflow and Feed Valve
Adjustable 360 View of Pressure Indicator
Large Adjustment Range
Serviceable without draining the system
One Piece Body Construction
Stainless Steel Strainer
