1/2″ Square Aluminum Water Gauge Less Glass & Rod (w/ Auto Ball Valve)

Description

Available with 1/2″ (ASTM B-16 brass bar stock) or 3/4″ (B-584 cast bronze) NPT male pipe connections. Four guard rods and EPDM gauge glass gaskets standard. Other glass gaskets available. Automatic ball checks help prevent the loss of fluids should the glass be broken.

Features:
Standard 1/4″ needle drain valve in lower arm
Pet cock or A p o l l o® ball valve drain on request
Ball checks standard on 2 0 – 3 5 0
Rated: 200 psig @ 400°F, 400 psig @ 100°F
CRN Registered

**Image is not exact representation of item.**
