11 Loop 1-1/2″ High Flow Stainless Steel Manifold w/ Flowmeter & Ball Valve (Fully Assembled)

Description

MrPEX 1-1/2″ Stainless Steel Manifold is made from high quality stainless steel,
and is offered in 2 through 12 loop configurations. The manifold comes mounted
on brackets and it is equipped with full port ball valves with thermometers,
manual air vents and fill/drain valves. The Cv is 1.39 per branch. Branch
connections are EK 25. The SUPPLY (upper) manifold is fitted with balancing
flowmeters with readable range of 0 to 2 GPM that allow flow adjustment of each
individual loop. The flow meters have a brass body and the sight glass is made
from temperature and impact resistant plastic, all components are antifreeze
resistant up to a 50% mix. The RETURN (lower) manifold, has manual on/off valves
that controls the flow for each individual circuit.
