15A, 125V NEMA L5-15R, 2P, 3W, Single Locking Receptacle, Grounding, Corrosion-Resistant (Yellow)

Description

Features
* L5-15R
* Leviton’s Industrial Grade Locking Devices are built to provide unparalleled
quality and superior performance in the most severe industrial settings.
Leviton combines the best materials available with superior production
standards to produce a broad selection of Locking Devices of unmatched
flexibility and dependability.

Specifications
* Color: Yellow
* Environment: Corrosive
* At Rated Voltage: 1/2 HP
* Amperage: 15 A
* Pole: 2
* Body Material: Nylon
* Terminal Screws: Nickel-Plated Brass 10-32
* Warranty: 10-Year Limited
* UL498: File E13399
* Wire: 3
* Country of Origin: Mexico
* Dielectric Voltage: Withstands 2000V per UL498
* Strap Material: Nickel-Plated Brass
* Terminal Accom.: 18-10 AWG
* Base Material: Nylon
* Face Material: Nylon
* Grounding Screw: Nickel-Plated Brass 8-32
* RoHS Compliant: FALSE
* ANSI: C-73
* UL Fed Spec WC-596: File E13399
* Current Limiting: Full Rated Current
* Grounding: Grounding
* Line Contacts: Nickel-Plated Brass .040 Thick
* Voltage: 125 VAC
* Flammability: Rated V-0 per UL 94
* NEMA: WD-6
* Yoke: Nickel-Plated Brass .050 Thick
* Termination: Side
* NOM: 57
* Product ID: Ratings and NEMA I.D. permanently marked on device
* CSA C22.2 No. 42: File LR-406
* Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
* Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
* Screw Terminal Torque: 14-18 in-lbs
* Operating Temperature: -40 °C to 60 °C
