15A, 125V NEMA L5-15R, 2P, 3W, Single Locking Receptacle, Isolated Ground, (Orange)

Description

Features
* Leviton’s line of Extra Heavy-Duty Industrial Grade locking receptacles are
designed and manufactured to withstand the harsh conditions typically
associated with industrial environments. Available in a wide variety of
configurations, including isolated ground, tamper-resistant, hospital grade,
etc., these Industrial Grade devices are the electrical contractor’s choice
for use in factories, schools, hospitals and commercial office buildings.
* L5-15R

Specifications
* Yoke: Zinc-Plated Steel
* Voltage: 125 VAC
* NOM: 57
* Warranty: Limited Lifetime Warranty Warranty
* UL Fed Spec WC-596: File E13399
* Strap Material: Nickel-Plated Brass
* Country of Origin: Mexico
* UL498: File E13399
* Grounding Screw: Brass 8-32
* RoHS Compliant: FALSE
* Color: Orange
* Terminal Accom.: 18-10 AWG
* At Rated Voltage: 1/2 HP
* Wire: 3
* ANSI: C-73
* Grounding: Isolated Ground
* Line Contacts: Brass .031 Thick
* Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
* Dielectric Voltage: Withstands 2000V per UL498
* Operating Temperature: -40 °C to 60 °C
* CSA C22.2 No. 42: File LR-406
* NEMA: WD-6
* Screw Terminal Torque: 14-18 in-lbs
* Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
* Termination: Side
* Body Material: Nylon
* Amperage: 15 A
* Terminal Screws: Brass 10-32
* Pole: 2
* Face Material: Nylon
* Environment: Dry
* Product ID: Ratings and NEMA I.D. permanently marked on device
* Current Limiting: Full Rated Current
* Feature: Isolated Ground
* Flammability: Rated V-2 per UL 94
