205 MAX Residential Heat Recovery Ventilator, 179 CFM

Description

Highest efficiency single core HRV on the market.Top port design for flexible installations, with door port balancing featuring the high efficiency HEX core.

Features:
High Efficiency Hex Core
Door Port Balancing & adjustable dampers
Excellent low temperature performance.
Top Ported. Controller with 5-speed, 4-mode operation, included.
Motors and Blowers – two independent motorized impellers
Core – HEX CORE is a counter flow heat exchanger that ensures maximum heat transfer, low pressure loss, constructed of thermally conductive and durable aluminum. With our recirculation defrost strategy the sensible heat recovery efficiency (SRE) at -25C (defrosting) can be within a few percent of the 0C SRE (no defrost) delivering significant energy savings. Each core is tested to ensure very low leakage.
Defrost – Recirculating
Serviceability – Latched door to allow easy access to core and filters for cleaning. 25″ clearance recommended.
Case – 20GA pre paint galvanized steel
Insulation- 3/4″ foil face Styrofoam
Filters – Washable on supply and exhaust
Mounting – Typically hung with supplied strap and hook kit.
