20A, 600V NEMA L9-20R, 2P, 3W, Flush Mtg Locking Receptacle, Grounding, V-0-MAX (Black)

Description

Features
* Operating Temperature: -40 °C to 60 °C
* Body Material: Nylon
* RoHS Compliant: TRUE
* Country of Origin: Mexico
* Terminal ID: Marked on Device
* Ground Contacts: Brass
* Dielectric Voltage: Withstands 2000V per UL498
* Grounding Screw: Chromated Brass
* NOM: 57
* UL: 498
* Terminal Clamps: Nickel-Plated Brass
* Grounding: Grounding
* Wire: 3
* Pole: 2
* UL Fed Spec: W-C-596
* Terminal Accom.: 14-8 AWG
* Current Limiting: Full Rated Current
* Screw Terminal Torque: 14-18 in-lbs
* Terminal Screws: Chromated Brass
* Color: Black
* CSA: C22.2 No. 42
* NEMA: WD-1 & WD-6
* Flammability: Rated V-0 per UL 94
* Base Material: Valox
* Termination: Back & Side
* Warranty: Limited Lifetime Warranty
* Product ID: Ratings and NEMA I.D. permanently marked on device
* Cover Material: Valox 357
* Voltage: 600 VAC
* Strap Material: Nickel-Plated Brass
* Line Contacts: Brass
* Face Material: Ultramid
* Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
* Amperage: 20 A
* ANSI: C-73
