3/8″ Compression MBV001 Mechanical Mixing Valve (Lead Free)

Description

Cash Acme’s Mechanical Mixer is designed for use under the sink. The valve mixes hot and cold water and delivers tempered water at a safe temperature.

NOTE: This is hot and cold mechanical mixing valve only. The Cash Acme mechanical mixing valve is NOT a temperature limiting device and does not provide automatic control of the water temperature.

Features:
3/8″ compression connections
Adjustment lever with lock screw
Brass valve with chrome-plated finish
The Mechanical Mixer allows for the mixing of hot and cold water to a point of use fixture
Designed to install under the lavatory
Quick and Easy Service/Repair
Brass Construction with a grit blasted, chrome plated finish
Stainless steel adjustment lever
Locking Mechanism prevents unwanted adjustments

Specifications:
Mechanical mixing valve that delivers water to a set hot and cold mix ratio, outlet temperature adjustable by manual lever
Maximum Supply Pressure: 125 psi
Maximum Supply Temperature: 180°F (93°C)
Service: Potable Water
Body: Lead Free Brass
Adjustment Lever: Stainless Steel
Size and Connection: 3/8�Compression
