7 Day, 5-2 Day Programmable Thermostat (1 Heat/1 Cool)

Description

Product Overview

The universal programmable thermostat shall be a Braeburnfi model number 2030, 4.25â€?high x 5.12â€?wide x 1â€?deep, powered with either 24 Volt AC or with two “AA”
Alkaline batteries (3.0 Volt DC). In the event of a power failure, the unit shall retain all user, installer and program settings. The thermo stat shall be compatible with low
voltage single stage gas, oil, or electric heating or cooling systems, and single stage heat pumps. Also compatible with 250mv �750mv millivolt heating only systems and
2 wire hydronic zone systems. The thermostat shall have a bright blue backlight display and a separate sub-base. Temperature control range shall be between 45° and 90°
F (7° and 32° C), accuracy of +/- 1° F (+/- .5° C) and operating humidity range between 5% and 95% relative humidity. The thermostat shall include separate installer and
user setup modes, permanent non-volatile memory to retain user settings, filter check monitor, adaptive recovery mode (ARMâ„? and installer lock mode.

Product Features
7 Day, 5-2 Day or Non-Programmable
Large 4.4 Sq. In. Display
Bright Blue Backlight
SmartLimit Temperature Limits
SpeedSet Programming Mode
Hardwire or Battery Powered
Installer Lock Mode
Filter Check Monitor
Optional Celsius Display
Separate O and B Terminals
Adaptive Recovery Mode (ARM )
Adjustable Temperature Differential
Compatible with 2-Wire Hydronic
Zone Systems
