C-485-G T/C 5/8″ ODF Catch-All Liquid Line Replaceable Core Filter Drier w/ Tube Construction (48 Cubic Inches)

Description

TYPE: C-485
CORE TYPE: RCW-48, RCW-4864, RC-4864-HH
CONNECTION SIZE (INCH): 5/8″ ODF
CONNECTION STYLE: 1/4″ Female Pipe Connection in the Flange Plate and Pipe Plug.
MOUNTING STANDARD: A-685
FILTER ELEMENT: Part Number-RPE-48-BD
FILTER AREA (IN2): 64
ADDITIONAL OPTIONS: Tube Construction
NOMINAL CAPACITY RANGE (TON): *RCW-48 OR RCW-100, RC-4864 OR RC-10098 Cores-(10)- Refrigeration- Commercial & Low Temp Equipment, (15) Air Conditioning- OEM Self Contained, (10) Air Conditioning- Field Replacement or Field Built-Up Systems
NUMBER OF CORES: 1
APPLICATION: Air Conditioning, Commercial Refrigeration, Low Temp Refrigeration
DESICCANT VOLUME (CU. IN.): 48
LENGTH (INCH): 9.15″
DIAMETER (INCH): 4 3/4″

The Replaceable Core Model Filter-driers – Sporlan Catch-All® Series provide unparalleled control of the most harmful contaminants in HVAC&R systems. Moisture, acids, and solid debris are effectively captured to ensure the long life, efficiency, and capacity of today’s high performance air-conditioning and refrigeration systems. Each Replaceable Core Model Filter-driers – Sporlan Catch-All® is factory tested to ensure trouble-free performance.

Markets:
Residential & Commercial HVAC
Food Service Refrigeration
Commercial Refrigeration
Specialty & Ultra-low Temperature Refrigeration
Transportation Air-conditioning and Refrigeration

Features/Benefits:
Complete contaminant control to protect and extend system life and ensure system reliability
High performance desiccant package provides high water & acid capacity
Porous molded core provides excellent filtration of solid debris for TEV and compressor protection
Models available with activated charcoal for use during system clean-up

Applications:
Heat Pumps
Air Conditioning – Residential, Commercial, Chillers
Refrigeration – Cases, Coolers, Walk in Coolers, Freezers
Transportation
