CX 8158 Concealed Battery/Hardwired Sensor Wall Mounted Water Closet Flushometer (1.28 GPF/4.8 LPF)

Description

CX 8158 (1.28 gpf) Concealed Battery/Hardwired Sensor Wall Mounted Water Closet
Flushometer

Specifications:
* Flush Volume: 1.28 gpf (4.8 Lpf)
* Finish: Polished Chrome (CP)
* Power Type: Battery with Hardwired Option
* Battery Life: 5 years
* Valve: Piston
* Bypass: Filtered
* Valve Body Material: Semi-red Brass
* Fixture Type: Water Closet
* Closet Mounting: Wall-mounted
* Fixture Connection: Rear Spud
* Rough-In Dimension: 12-5/8″ (321mm)
* Spud Coupling: 1-1/2″ (38mm)
* Supply Pipe: 1″ (25mm)
* L Dimension: 3-1/4″ to 4-1/4″ (83 to 108 mm)
* Override: Electrical (OR)
* Wall Box: Front Accessible
* Control Stop: Integrated
* Vacuum Breaker: Short V500A & Adjustable Flus
