ECOS 8111-1.6/1.1 Exposed Sensor Battery-Operated Dual-Flush Water Closet Flushometer (1.6 GPF/1.1 GPF)

Description

The Sloan ECOS is an exposed, sensor activated batter-powered, electronic dual flush water closet Flushometer (for either left or right hand supply) for floor mounted or wall hung top spud bowls.

If the user is present for less than one minute and leaves the sensing zone or chooses the small override button, a reduce flush initiates (1.1 gpf/ 4.2 Lpf), eliminating liquid and paper waste, saving 1/2 gallon of water.

If the user is present for greater than one minute and leaves the sensing zone or chooses the large override button, the full flush initiates (1.6 gpf/ 6.0 Lpf), eliminating solid waste and paper waste.

Features:

Flush Cycle – Full Flush (Large Button – 1.6 gpf/ 6.0 Lpf), Reduced Flush (Small Button – 1.1gpf/ 4.2 Lpf)
Reduces water volume by up to 30% when a reduced flush occurs
PERMEX Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass
ADA Compliant Sloan ECOS® Electronic Dual Flush Battery Powered Infrared Sensor for automatic “No Hands” operation
Infrared Sensor with Multiple-focused, Lobular Sensing Fields for high and low target detection
Latching Solenoid Operator
Engineered Metal Cover with replaceable Lens Window
User friendly three (3) second Flush Delay
Courtesy Flush Override Button
(4) Size AA Batteries factory installed
“Low Battery” flashing LED
Infrared sensor range adjustment screw
Initial Set-up Range Indicator Light (first 10 minutes)
1″ I.P.S. Screwdriver Bak-Chek® Angle Stop
Free Spinning, Vandal Resistant Stop Cap
Adjustable Tailpiece
High Black Pressure Vacuum Breaker Flush Connection w/ One-Piece Bottom Hex Coupling Nut
Spud Coupling & Flange for 1-1/2″ Top Spud
Sweat Solder Adapter w/ Cover Tube and Case Wall Flange w/ Set Screw
High copper, low Zinc brass castings for dezincification resistance
Fixed metering bypass and no external volume adjustment to ensure water conservation
Flush Accuracy Controlled by CID Technology
Diaphragm, Stop Seat and Vacuum Breaker molded from PERMEX Rubber Compound for Chloramine resistance
