HG110-HX , 3/4″ Heatguard Thermostatic Mixing Valve w/ Sharkbite Connectors and Integral Checks (Lead Free)

Description

Product Overview:
The Heatguard 110-HX is a Temperature Actuated Mixing Valve that mixes
hot water with cold to deliver hot water at a reduced temperature.
The Heatguard® 110-HX has an outlet temperature range extending to 176°F
(80°C), making it ideal for applications in heating systems or in any installation
requiring the delivery of reduced temperature hot water.
The Heatguard® 110-HX is a high quality mixing valve incorporating the latest in
thermostatic technology. It features a robust design based on the expertise
gained from years of experience in the design and manufacture of safety valves.
Every valve is tested for performance on an automated testing station during the
assembly process. The valve is third party listed.
The Heatguard® 110-HX incorporates a fast acting, high quality thermostatic
element that senses the outlet water temperature and reacts to maintain a
stable delivery water temperature even under changing flows or variations in
supply temperatures.
The Heatguard® 110-HX is shipped complete as a kit with your choice of end
connections in 1/2\
