MODA 1-Valve CPVC (Female) Toilet and Dishwasher Supply Box with Hammer Arrestor, 37906

Description

The MODA Supply Box System is a compact, universal single-box platform that
combines extensive mounting configuration options with innovative engineering,
simplifying outlet box installation for plumbing contractors. One universal
faceplate is compatible with all box types, and boxes easily snap to one another
with common brackets. Available in standard and fire-rated options, MODA Toilet
and Dishwasher Supply Boxes include one 3/8 in. outer diameter compression valve
pre-installed in a PVC box with sturdy interlocking wing flanges that allow for
on-stud and straddle-stud installations. Oatey products have earned the trust of
plumbing professionals for over 100 years.

Features:
* MODA compact-size toilet and dishwasher outlet box
* Infinite configuration options for easy, flexible installation
* Connects to CPVC supply line with solvent weld connection
* Two-piece valve design for easy repair or replacement without damaging
drywall
* Advanced snap-lock design allows for easy assembly/disassembly and connection
to another MODA box
* Contains (1) 3/8 in. outer diameter compression valve pre-installed in a PVC
box with interlocking wing flanges that accommodate on-stud and straddle-stud
installation
* Separate valve and drain boxes allow paired or split boxes between walls or
stud bays to prevent supply/drain crossovers; valves rated to 150 PSI air and
250 PSI water
* Durable PVC box construction stands up to the roughest jobsite conditions
* Universal faceplate and brackets compatible with all MODA boxes
* Box dimensions: 8 in. W x 4.85 in. H x 3.38 in. D; box opening dimensions:
3.82 in. W x 4.367 in. H
* Faceplate dimensions: 6 in. W x 6.45 in. H
* Includes (1) Oatey Quiet Pipes hammer arrestor to reduce noise and protect
pipes
