Model 918 Hydraulic Roll Groover for 1″ to 12″ Pipe

Description

The RIDGID Model 918 Hydraulic Roll Groover features a powerful 15-ton hydraulic ram in a compact, easy to transport unit. With one man set-up and operation, the 918 is the ideal groover for job site requirements. The 918 mounts quickly to RIDGID 300 power drive, 535, 1822, or 1224 Threading Machines (sold separately). Designed to provide maximum efficiency, the 918 is capable of grooving up to 12″ Schedule 10 and 8″ Schedule 40 standard wall pipes.

Product Features:

Compact lightweight design allows for easy transport
Extensive grooving capacity for a wide range of applications
Rugged, durable housing enables unit to withstand harsh use
Two-stage pump plus 15 ton ram permit quick and smooth operation
Quick easy set-up. Easy rollset changeout
Specifically designed groove and drive rolls product consistent, accurate grooves throughout the capacity range

Pipe Capacity

Schedule 10 Steel, Stainless Steel: 1″ – 12″
Schedule 40 Steel, PVC: 1″ – 8″
Schedule 40 Stainless Steel: 1″ – 2″
Copper Type K, L, M, & DWV: 2″ – 6″
Schedule 80 PVC: 2-1/2″ – 4″
