Model D267 Waste-Mate Automatic Cast Iron Sewage Pump – 230 V, 1/2 HP

Description

Submersible sewage/*effluent or dewatering pump
Features:
Float operated, submersible (NEMA 6) 2-pole mechanical switch
Durable cast construction, ASTM Class 25 cast iron, switch case and pump housing
Cast iron base on models 267 and 268
Engineered plastic base on model 266
Non-Clogging Vortex Impeller Design. Engineered plastic impeller with metal inserts on models 266, 267 & 268 (1 PH).
Not affected by materials normally found in drainage and sewage pumps
Stainless steel screws, bolts, handle, guard and arm and seal assembly
Neoprene square ring & gasket
Oil-filled, hermetically sealed motor
Oil lubricated bearings
Carbon and ceramic shaft seal
Passes 2″ spherical solids
2″ NPT discharge
On point: 12″ (automatic units); Off point: 4″ (automatic units)
Corrosion resistant powder coated epoxy finish
Completely submersible
Watertight and dust tight
Automatic reset thermal overload protection (1 Phase only)
Reserve powered design. For unusual conditions a reserve safety factor is engineered into the design of every Zoeller pump.
*May be used in those states where codes do not restrict solids size in effluent systems.
