Model M3282 High Temperature Submersible Pump – 115V, 0.5 HP

Description

Features
A High temperature submersible pump series with
electrical components meeting the National
Electrical Code requirements for 200° F service
Comprehensive line of models, styles and modes
Conduit length is 3 feet for automatic models and 6 feet for nonautomatic models
Power cord length is 15 feet for automatic models and supplied by others for nonautomatic models
High temperature liquid-tight conduit used with high
temperature cable
High temperature motor windings
High temperature Viton® gaskets
High temperature thermal overload protected
All control components in contact with the water are high temperature rated
All models have vortex impeller design
All models have stainless steel screws, guards, handles and control arm & seal assemblies
Float operated mechanical switch box which is mounted on the discharge pipe above the operating level (Switch box is not intended to come in continuous contact with 200° F water)
Mechanical seal has NI-Resist rotary face and Viton® elastomer
Corrosion-resistant powder coated epoxy finish
