REFMATE-2-CA-WTC, Two-Way Digital Manifold

Description

The REFMATE is the Digital Manifold for the professional refrigeration engineer. It communicates wirelessly with temperature clamps, pressure gauges, and the scale, and documents all measured values in the device during long-term measurements. All data can be interpreted and displayed via the app REFMESH. The latest refrigerant and firmware updates can be easily installed via PC.

Features:
Patented analog display (US patent 9’448’140)
Large 4.3″ TFT display
Indication of superheating and subcooling
Intuitive control via robust push buttons
High precision with accuracy class 0.5
Flexible power supply (AA batteries or USB)
Wireless communication with REFMESH App and other devices
All mechanical components are available as spare parts
Lockable for long-term measurements

Specifications
Number of Ways: 2-way
Pressure Range: -14 – 870 psi
Accuracy Class: 0.5 (+/-0.5%)
Pressure Scale: bar | psi | kPa | MPa | kg/cm2
Resolution: 0.001 bar, 0.5 psi, 1 kPa, 0.0001 MPa, 0.01 kg/cm2
Temperature measuring range: -40 – 257 F
Temperature Accuracy: +/-1
Temperature Resolution: 0.1 C / 0.1 F
Sensor type: K-type /Piezo Sensor
Operating Temperature Range: -4 -122 F
Storage Temperature Range: -4 -140 F
Battery: 4 x AA / 3 x AAA / Alternative Power Supply USB Mirco-B
Ingression Protection: IP42
Operating Hours: 50 h at low operation
Gas Connection: 1/4″ SAE
Signal Range: 300 ft
Number of Hoses: 3
Length: 60″
Device connection: 1/4″ SAE
System Connection: 1/4″ SAE
Ball Valve: Yes
Sealing: Neoprene
Packaging: Sturdy plastic case
Material: Aluminium/Brass/ABS/TPE
Color: yellow (RAL 1023) | green (RAL 6026)
Standards: CE / FCC / IC / RCM / RoHS / REACH
RoHS Conformity: Yes
