RPE-48-BD Replaceable Core & Filter (48 Cubic Inches)

Description

Sporlan Type Replaceable Cores and Filters primary purpose is to provide unparalleled control of the most harmful contaminants in HVAC & R systems. Moisture, acids, and solid debris are effectively captured to ensure the long life, efficiency, and capacity of today’s high performance air-conditioning and refrigeration systems. The cores can remove moisture, acids, dirt, and contaminants. The filter will remove solid contaminants in the piping following installation.

Markets:
Residential HVAC
Commercial HVAC

Features/Benefits:
Order as a separate
item—Fits types C-480 thru C-19200
Series shells and Replaceable Suction
Filter (RSF) shells.
This element should
be used in RSF shells installed in the
suction line to obtain the lowest possible
pressure drop after cores were used for
system clean-up.
Replaceable pleated filter elements
Replaceable pleated filter elements can be used with desiccant cores for clean-up after burnout, if certain precautions are followed
Highly effective filtration at low cost
Low pressure drop due to a large filtering area
Replaceable Cores provide complete contaminant control to protect and extend system life and ensure system reliability
Replaceable Cores high performance desiccant package provides high water & acid capacity
Porous molded Replaceable Core provides excellent filtration of solid debris for TEV and compressor protection
Replaceable Cores models available with activated charcoal for use during system clean-up
