Series 41 Manifold w/ 2-1/2″ Refrigerant Gauges (R410A)

Description

The Yellow Jacket 41712 is a 2 valve charging manifold only (no hoses included) that has a forged body of solid brass for durability. Full porting maximizes capacity. Metal valve handles are full size for easy operation. It features easy-to-read, accurate bold numbered, colored scales. These scales have 2-1/2″ (63.5 mm) gauge faces made up of rugged steel and polycarbonate crystal cases. The refrigerant scales and pressure arcs are color-coded for convenience and the numbers are large for high visibility. Hose anchors are forged into back of body at 45 degrees.

This manifold can only be used with R-410A refrigerant. Surge protection and silicon dampened movement provided by Flutterless technology minimize needle pulsation for easier, more accurate readings. This manifold product is designed for the air conditioning and refrigeration service technician who knows and appreciates the quality and durability of Yellow Jacket Products.

Features:
Easy to read 2-1/2″ steel case gauges with 3-2-3% accuracy
LOW Side Gauge: -30″ to 0 to 300 PSI
HIGH Side gauge: 0 to 800 PSI
Flutterless technology helps minimize needle pulsation for easier, more attractive readings
Forged Body is solid brass for durability
Manifold only, No hoses included
Full porting maximizes capacity
Metal valve handles are full size for easy operation
Hose anchors are forged into back of body at 45 degrees
Sliding double “O” ring piston for reliability and long service life
R-410A refrigerant only
Limited lifetime warranty on manifold bar and valves, NOT gauges
Made in the USA
