Smart Heat Pump Control, 4 tN4 Zones, Domestic Hot Water, Web & Mobile App

Description

The Smart Heat Pump Control 291 operates up to 4 heat pumps in a 2-pipe or
4-pipe configuration. The system can be built out with expansions to customize
systems for maximum home comfort. The system can deliver heating and cooling of
buffer tanks simultaneously (in 4-pipe configuration) and be expanded to support
up to 16 heat pumps, up to 3 mix temperatures, and support a dedicated boiler
loop. The Nexa by Watts web and mobile applications provide real-time remote
monitoring, setting adjustments, and notifications.

Features:

* Flexible heat pump system design with optional add on modules
* Remote access using Nexa by Watts web/mobile app and notifications through
email, or text
* Operates 4 heat pumps, expandable up to 16 using expansion controls
* 2-pipe or 4-pipe configurations, simultaneous heating and cooling of buffer
tanks (4-pipe only)
* Central heating/cooling using outdoor reset with up to 3 mix temperatures
using expansion modules
* Supports a back up boiler or a back up boiler loop with a Tekmar Smart Boiler
Control 294
* 5-inch color touchscreen with Setup Wizard for simplified installation

Specifications:

* Agency Approvals: CSA C US, FCC Part 15B, ICES-003 Class A
* Ambient Conditions: Indoor use only, 32 to 122 degrees F (0 to 50 degrees C),
less than 90 percent RH Non-condensing, Altitude Less Than 6560 feet (2000
m), Installation Category II, Pollution Degree 2
* Dimensions: 9 IN H x 8 IN W x 2 11/32 IN D (229 x 203 x 60 MM)
* Display: 5 IN color touchscreen
* Enclosure Material: Blue ABS Plastic
* Enclosure NEMA Rating: NEMA 1
* Markets: Multifamily Homes, Single-Family Homes, Small Commercial Buildings
* Modulating Output:0-10 V (dc) 500 ohms minimum load impedance / 4-20 mA 1 k
ohms max load impedance
* Power Supply: 115 V (ac) plus / minus 10 percent, 60 Hz, 7 W
* Pump Power: 230 V (ac), 5A, 1/3 hp
