tN2 House Control for Zone Valves

Description

Overview:
The House Control 402 is designed to operate as part of a complete hydronic heating system with tekmarNet®2 (tN2) thermostats. It can provide operation of two outdoor reset water temperatures in addition to Domestic Hot Water and Setpoint capabilities. It is easy to add more zones, add schedules or other convenient accessories through the use of the tekmarNet®4 (tN4) Expansion terminals.
Features:
Enclosure: O-Enclosure, blue PC+ABS UL94-5VA plastic
Approvals: CSA C US, meets ICES & FCC regulations for EMI / RFI
Ambient Conditions: Indoor use only, 32 to 104°F (0 to 40°C), RH 90% Non-condensing
Power Supply: 24 V (ac) ±10% 60 Hz, 100 VA max, Class 2
Control Load: 2 VA
Zone Valve/Floating Action Load: d24 V (ac) 2 A, maximum combined current (zones 1 to 4): 89 VA (3.7 A)
Boiler Relay: 24 V (ac) 5 A
Boiler System Pump Relay: 115 V (ac) 5 A, 1/6 HP
Mix System Pump Relay: 115 V (ac) 5 A, 1/6 HP
DHW Pump Relay: 115 V (ac) 5 A, 1/6 HP
Variable Speed Pump Relay: 115 V (ac) 5 A, 2.0 A
Pump Power: 115 V (ac) 12 A max
Setpoint and DHW Calls: Short, 0 – 32 V (ac)
Boil/Mix Modulating Output: t0 – 10 V (dc), 3 kohm minimum load impedance
