20A, 125/250V NEMA L10-20R, 3P, 3W, Flush Mtg Locking Receptacle, Non-Grounding, V-0-MAX (Black)

Description

Features
* UL: 498
* Voltage: 125/250 VAC
* Cover Material: Valox 357
* Terminal Accom.: 14-8 AWG
* NEMA: WD-1 & WD-6
* Flammability: Rated V-0 per UL 94
* ANSI: C-73
* Terminal Clamps: Nickel-Plated Brass
* Terminal ID: Marked on Device
* At Rated Voltage: 2 HP L-L/1 HP L-N
* NOM: 57
* Amperage: 20 A
* Operating Temperature: -40 °C to 60 °C
* RoHS Compliant: FALSE
* Line Contacts: Brass
* Face Material: Ultramid
* Ground Contacts: Brass
* Country of Origin: Mexico
* Body Material: Nylon
* Grounding Screw: Chromated Brass
* Current Limiting: Full Rated Current
* Color: Black
* Product ID: Ratings and NEMA I.D. permanently marked on device
* Base Material: Valox
* Grounding: Non-Grounding
* Dielectric Voltage: Withstands 2000V per UL498
* Termination: Back & Side
* UL Fed Spec: W-C-596
* Terminal Screws: Chromated Brass
* CSA: C22.2 No. 42
* Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
* Warranty: Limited Lifetime Warranty
* Pole: 3
* Strap Material: Nickel-Plated Brass
* Screw Terminal Torque: 14-18 in-lbs
* Wire: 3
