Locking Plug, 20A, 125/250V Industrial Grade (Black) & White

Description

Features
* Back Cover: Thermoplastic
* UL Fed Spec WC-596: File E13393
* UL498: File E13393
* Device Type: Locking Plug
* Brand: Black and White
* Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
* Amperage: 20 A
* At Rated Voltage: 2 HP L-L/1 HP L-N
* Blades/Contacts: Solid Brass
* Clamp Insert: Nylon
* Warranty: Limited Lifetime Warranty
* Grounding: Non-Grounding
* Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
* Voltage: 125/250 VAC
* NOM: 57
* Operating Temperature: -40 °C to 60 °C
* Product ID: Ratings are permanently marked on device
* Terminal Screws: Brass
* Current Interrupting: Certified for current interrupting at full rated
current
* CSA C22.2 No. 42: File LR-406
* Wire Module: Nylon
* Assembly Screws: Steel, Zinc Plated
* Pole: 3
* Flammability: Rated HB or better UL94
* Dielectric Voltage: Withstands 2000V per UL498
* Wire Gauge: 16-10 AWG
* Environment: Dry
* Wire: 3
* Cord-Clamp: Nylon
* Country of Origin: Mexico
* Body Material: Impact Modified Nylon
* NEMA: WD-6
* ANSI: C-73
* Cord Range: .385 – .780
* Color: Black-White
* Terminal Accom.: 18-10 AWG
* RoHS Compliant: TRUE
